PGW XL pneumatic grid cutter

The PGW XL pneumatic grid cutter is suitable for cutting fruit and vegetables with a large diameter into many different cutting shapes. It is also available in a design specially adapted for the processing of cabbage.

600 cuts/hMax. capacity
Pneumatically operated cutting machine PGW XL for various cutting shapes for large fruits and vegetables.

Your benefits

  • Specially adapted for the processing of products with a large diameter
  • Versatile use thanks to a large selection of cutting inserts
  • Fast tool change
  • Simple operation

Product groups


Portrait

A wide variety of cutting shapes for processing large products

The pneumatically operated PGW XL is especially adapted for processing products with a large diameter of up to 300 mm. The variety of cutting inserts enables different fruits and vegetables to be peeled, cored, segmented or cut into many different shapes such as cubes, strips, slices or sticks. Special punching forms for making diamonds, boats, and disks in various sizes, as well as decorative shapes (stars, hearts and many more) and grid inserts, are also available. The cutting inserts can be used in the PGW and PGW XL.

A PGW XL especially adapted for cabbage processing is available on request for coring and dividing in one step.

Manufacturing process (except when processing cabbage): The product to be processed is positioned manually on the mounted cutting insert. Pressing the buttons activates the cutting process and, depending on the knife used, the product is punched into the appropriate shape. The cut product falls down into a prepared container or onto a conveyor belt.

In the standard version, the PGW XL is a tabletop device; a mobile base frame is optionally available.

Fig. shows a machine with special equipment or a customized design.

Show more Show less

Benefits

The product holding area of the PGW XL is specially adapted to large products

Flexible processing of large-caliber products

Thanks to the large selection of cutting inserts, the PGW XL can process a large number of products with larger diameters into various cutting shapes. In addition to the standard types of cuts, many special punching forms and customer-specific designs are available.

Show more Show less
The cutting inserts of the PGW XL can be changed quickly and easily.

Quick change of product or cutting form

The PGW can be quickly cleaned and converted. No additional tools are required to change the cutting inserts.

Show more Show less
Two-hand operation enables a high level of work safety when operating the PGW XL

User-friendly and quick to clean

The PGW is easy to operate, quick to clean and requires little maintenance, which makes it particularly user-friendly. The  two-hand operation ensures a high level of work safety.

Show more Show less

Accessories

Every cutting insert consists of a knife insert including insert plate and ram including ram plate.
A large selection of different cutting inserts

The PGW XL enables the processing of a wide variety of products with a large diameter into a wide range of cutting shapes. Inserts for cutting slices, strips, cubes and sticks, as well as for segmenting products, are available.
Each insert consists of the knife insert including the insert plate and the pusher including the pusher plate
Cutting inserts can be made in individual shapes according to a template for customers on request.

Show more Show less
Mobile base for the PGW XL grid cutting machine
Mobile base frame for mobility and flexibility

A stable base is a prerequisite for the safe and optimal operation of the PGW XL. The mobile stainless steel base frame also simplifies the flexible use of the machine and the cleaning of the work areas.

Show more Show less
400 - 600 cuts/h
Capacity
Semi-automatic

The capacity depends on factors such as the product.

Air Working pressure 6 bar
Air consumption 34 NL / 42 NL per cycle
Dimensions LxWxH 620 x 500 x 1120 (depending on design)
Weight 57 kg (depending on design)
Infeed/placement height 1140 mm (with mobile base frame)
Miscellaneous Diameter of raw product max. 300 mm
Height of raw product max. 220/300 mm
The data indicated are standard information. In addition, adaptation to other supply networks (e.g. 230V/60 Hz) is optionally possible (except for manual and pneumatic machines). Subject to changes.
