KS-7 PLUS vegetable and lettuce spin-dryer

As the standard model of the KRONEN vegetable and lettuce spin-dryers, the KS-7 PLUS offers an ergonomic design and seven spinning speeds for drying lettuce, vegetables, fruit and many other products.

up to 1,250 kg/h   Max. capacity
Get information/offer
PDF Preview

Your benefits

  • Easy-to-clean spinning area without dirt traps thanks to a hygienic design
  • Ergonomic lift-in height
  • Optimal water drainage
  • Robust design and safe operation

Product groups

Portrait

User-friendly and gentle spinning PLUS optimal hygiene

The KS-7 PLUS is the standard model of the KRONEN vegetable and lettuce spin-dryers. It spin-dries a wide range of products from lettuce to cut vegetables and fruit and right through to canned products, pickled food products or caviar efficiently and reliably with seven spinning speeds.
The KS-7 PLUS vegetable and lettuce spin-dryer can be integrated into processing lines or used as a stand-alone machine. As a component of processing lines, it is positioned downstream of the washing process, after which the washed products are filled into the spin baskets and manually placed into the KS-7 PLUS.

The robust, open design enables

  • ergonomic operation due to the low lift-in height
  • Optimal hygiene: no dirt traps due to screws etc. in the spinning area
  • Easy water drainage for an optimal spin-drying result

The spin-dryer is suitable for processing lettuce, herbs, cut fruit and vegetables and many other products. It also reduces the dripping-off times of canned products such as mushrooms and pickled vegetables or defrosted products. Other food products such as prawns, caviar (substitute) or even sesame seeds can also be spun dry with the spin-dryer. Mesh inserts for the spin baskets are optionally available for fine-particle products. Depending on the product, the machine achieves high capacities and a low residual moisture content of the products.

Show more Show less
Get information/offer

Videos

KS PLUS – gentle and effective spinning and drying of salads and vegetables
The KS-100 PLUS, KRONEN’s top-selling spin-dryer for vegetables and salads, is a field-tested machine with hundreds of models in operation worldwide.
Show more Show less

Benefits

The open design makes the spin-drying area easily accessible for cleaning

Easy and quick cleaning due to an open, hygienic design

The open design makes the centrifuge area easy to access for quick cleaning and maintenance work. In addition, there are no dirt traps caused by screws in the spin area, and the lid locking mechanism is also located in the rear machine housing.

Show more Show less
KRONEN benefits

User-friendly even when frequent product changes are necessary

The ergonomic lift-in height and the lid locking mechanism, which prevents the centrifuge from being opened during the spin cycle, make the spin-dryers particularly user-friendly. The powerful and low-noise motor ensures low wear and a long service life. All in all, the machine is very easy to maintain.

Show more Show less

Accessories

Easily stackable plastic baskets which are placed into the spin-dryer
Matching plastic baskets

The lightweight, stackable plastic baskets with carrying handles are filled with the wet (washed) product and inserted into the rotating basket of the spin-dryer.

Show more Show less
The mesh insert can be placed into the basket for the processing of small products
Mesh insert for fine products

With the help of the mesh insert for the plastic baskets, even fine-particle and sensitive products such as herbs or seeds can be spun dry without any problems. The fine nylon filter keeps even very small products in the basket.

Show more Show less
The basket carousel serves as a link between the washing machines and the vegetable and salad spin-dryers
Basket carousel as an efficient link

The basket carousel is a practical link between the KRONEN washing machines and the KRONEN vegetable and lettuce spin-dryers. It ensures a continuous workflow, simplifies the change of baskets and catches possible product overflows in the stainless steel container.

Show more Show less
The basket slide connects a washing machine with the vegetable and salad spin-dryer
Basket slide for transport from the washing machine to the spin-dryer

The basket slide is another way to connect a KRONEN washing machine with the vegetable and lettuce spin-dryer. It is available in a straight or angled configuration.

Show more Show less
KRONEN accessories
Stainless steel basket insert

A stainless steel basket insert is also available as an alternative to the mesh insert.

Show more Show less
up to 1,250 kg/h
Capacity
Batch
Loading type

The capacity depends on factors such as the product.

Electrical power Power 0.8 kW
Voltage 230 V
Frequency 50 Hz
Dimensions LxWxH 954 x 644 x 985 mm
Weight 160 kg
Miscellaneous Spin speed 250–850 rpm
Basket volumes 44 l
The data indicated are standard information. In addition, adaptation to other supply networks (e.g. 230V/60 Hz) is optionally possible (except for manual and pneumatic machines). Subject to changes.
PDF Preview
pdf
Download
Get information/offer
